Setting up a Travel Router with VPN Back to Your Home Network

Posted Updated
Preview Image
By Kuibin Lin
views 5 min read
Setting up a Travel Router with VPN Back to Your Home Network

Why You Might Want to Do This

Your GL.iNet travel router is capable of much more than simply repeating hotel or public Wi-Fi. Without a VPN, it passes traffic from those networks directly to your devices — traffic that might be unencrypted or exposed.

While it’s convenient — your devices only need to connect to your travel router’s SSID once — public networks (hotels, airports, cafés) might not be secure. The travel router acts as a middle layer, handling the Wi-Fi login and sharing connectivity with all your devices, but it doesn’t protect your traffic unless you enable a VPN.

Some countries also restrict access to websites like Google, YouTube, or social platforms. A VPN helps bypass such restrictions by routing your traffic securely through your home network.

If you also run a Pi-hole DNS server at home, you can route all DNS queries through it to block ads, trackers, and log DNS usage — further increasing privacy.

This guide will show you how to:

  • Configure WireGuard VPN on your GL.iNet router.
  • Set up a guest network to isolate untrusted devices.
  • Add firewall rules to prevent guests from accessing your home network.
  • (Optional) Allow guests to use your home DNS server securely over the VPN.

What You’ll Need

  • GL.iNet Travel Router (e.g., GL.iNet Slate 7 (GL-BE3600): product link)
  • A home VPN server running WireGuard (This guide assumes you host your own VPN. Not intended for commercial VPNs.)
  • WireGuard client configuration that allows LAN access and DNS routing
  • (Optional) A Pi-hole or other DNS server running at home

Step 1: Set Up WireGuard VPN Client on the GL.iNet Router

Goal:

Securely route all internet traffic through your home network — so your connection appears as if you’re browsing from home, even when travelling.

Example: If you’re in a hotel in China, but your VPN server is in the UK, using the VPN allows you to access YouTube, Gmail, or any content restricted locally.

Instructions:

  1. Power on your GL.iNet router.
  2. Connect to the router’s Wi-Fi from your laptop or mobile (the SSID and password are printed on the device).
  3. Open a browser and go to http://192.168.8.1 to access the router’s web interface.
  4. Navigate to VPN > WireGuard Client.
  5. Click “Add a New VPN Configuration”, assign a name, and import or paste your WireGuard config. Example:
1
2
3
4
5
6
7
8
9
10

[Interface]
PrivateKey = <your private key>
Address = 10.0.0.100/24
DNS = 192.168.1.80

[Peer]
PublicKey = <your home server public key>
PresharedKey = <optional preshared key>
Endpoint = yourhome.ddns.net:51820
AllowedIPs = 0.0.0.0/0, ::0/0
  • DNS = 192.168.1.80: points to your home Pi-hole server
  • Endpoint: use your home’s static IP or a dynamic DNS address
  1. Click Save, then Connect.

Now all devices connected to the GL.iNet router will tunnel their internet traffic securely through your home.

Optional: Set the Physical Toggle Switch for VPN

  1. Go to System > Toggle Button Settings.
  2. Assign the toggle switch to WireGuard Client (on/off).

This allows quick VPN control via a physical switch on the router.

Goal:

Isolate less secure or guest devices from your own — such as family phones, smart TVs, or IoT devices.

Instructions:

  1. In the GL.iNet interface, go to Wireless > Guest Wi-Fi.
  2. Enable the Guest SSID.
  3. Navigate to Network > Guest Network, and ensure Client Isolation is ON.

Why this is important: Devices on the guest network cannot see each other or access the router interface. This prevents accidental or malicious access to your own devices.

Step 3: Block Guest Clients from Accessing Your Home Network via VPN

Problem:

Even though guests are isolated locally, traffic from the guest network still goes through the VPN — meaning they could access your home LAN (e.g., 192.168.x.x, 10.x.x.x, 172.16.x.x) if not blocked.

Solution:

Use a firewall rule to block all guest traffic going to common private IP ranges via VPN.

Instructions (in LuCI interface):

  1. Go to System > Advanced Settings to open LuCI.
  2. Navigate to Network > Firewall > Traffic Rules.
  3. Click Add, and fill in:
FieldValue
NameBlock Guest to Home Network
ProtocolTCP + UDP
Source zoneguest
Source addressleave blank
Source portany
Destination zonewgclient (your VPN zone)
Destination address192.168.0.0/16, 172.16.0.0/12, 10.0.0.0/8
Destination portany
ActionDrop

Click Save & Apply.

Why this is important: This ensures guest devices can access the internet via the VPN, but not your home network — protecting your NAS, printers, or internal services.

Step 4: (Optional) Allow Guest Access to Your Home DNS Server (Pi-hole)

Only do this if:

You want guest devices to use your home DNS server (e.g., Pi-hole) for DNS filtering and logging, rather than public DNS (e.g., Google or Cloudflare).

(A): Edit the Default GL.iNet DNS Forwarding Rules

  1. Go to LuCI > Network > Firewall > Port Forwards.

  2. Edit the following two rules:

    • dns for vpn → source zone: lan
    • dns for vpn guest → source zone: guest

  3. Update:

    FieldValue
    Internal IP address192.168.1.x (your Pi-hole)
    Internal port53

(B): Add a Traffic Rule to Allow Guest DNS

  1. Go to Network > Firewall > Traffic Rules.
  2. Click Add, and fill in:
FieldValue
NameAllow Guest DNS to Pi-hole
ProtocolTCP + UDP
Source zoneguest
Source addressleave blank
Source portany
Destination zonewgclient
Destination IP192.168.1.x (your Pi-hole IP)
Destination port53
ActionAccept

Click Save & Apply.

Why this is useful: This ensures guest clients can use your home DNS server for name resolution — without giving them access to anything else in your home network.

Understanding Firewall Rule Order

  • You do not need to reorder firewall rules manually.
  • OpenWrt (used by GL.iNet) processes rules based on specificity, not visual order.

Example:

  • A rule that allows DNS to 192.168.1.80:53 will override a broader block to 192.168.0.0/16.
  • If you remove the allow rule, the block rule takes full effect.

✅ Final Outcome

  • ✅ A secure travel router that encrypts all traffic via your home VPN
  • ✅ A guest network that protects your trusted devices
  • ✅ A firewall that blocks guests from accessing your home LAN
  • ✅ (Optional) Controlled DNS routing for better privacy and filtering
  • ✅ Easy control via a toggle switch for the VPN
